29. Spare Parts
i
The pictures of spare parts can be found on the page that folds out at the end
of the operating manual.
Spare Parts List: Spray lance (Fig. A1)
Pos. Designation Order No.
1,2 Spray jet adjustment ring, union nut * 2363 209
3,4,5,6 Nozzle set * 2363 210
6 Nozzle seal (2 pcs.) 2344 774
1-7 Complete spray head * 2363 212
8 Spray head cover 2363 211
9 O-ring 2323 068
9,10 Spray lance * 2363 213
Spare Parts List: Standard spray attachment (Fig. A2)
Pos. Designation Order No.
Standard spray attachment complete with 800 ml container 2361 730
1 Union nut 2362 873
2 Air cap 2362 877
3 Nozzle 2362 878
4 Nozzle seal 0417 706
5 O-ring of spray attachment 2362 875
6 Ventilating hose, valve cover, diaphragm 2304 027
7 Suction tube 2362 876
8 Container seal 2323 039
9 Container with cover 800 ml 0413 909
Spare Parts List: W 950 Flexio (Fig. A3)
Pos. Designation Order No.
1 Air hose 2362 918
2 Securing clip 2365 340
3 Material hose and control hose * 2362 919
4 Complete suction hose 2362 920
5 Air lter cover 2362 921
6 Air lter (2pcs.) 2310 812
7 Grab handle for Click&Paint spray attachments 2362 879
8 Adapter for Click&Paint grab handle 2344 437
9 Stirring rod 2304 419
Lubricating grease 2315 539
