GB
8
Spray gun W 140 P
Spray Technique
● Cover areas that are not
to be sprayed. When woriking keep in mind that wind, for
example, may transport paint mist over great distances and cause damage.
● Test the spray gun on cardboard or a similar surface to find the correct setting.
● When spraying, hold the spray gun in a horizontal position. Use the flexible nozzle
extension (Illus. 7, arrow, special accessories) for spraying upwards (e.g. a ceiling)
or downwards (e.g. an unhinged door laid on the floor).
● The spray movement should come from the arm, not just from the wrist. This
ensures that a uniform distance is maintained between the spray gun and the spray
surface during the spray operation (Illus. 4).
● To achieve optimal spray results, spray back and forth over the surface (Illus. 5).
Cleaning and Maintenance
The spray gun can only operate satisfactorily if it is cleaned and preserved after each
use.
Attention! Never immerse the spray gun in liquid when cleaning.
1 Empty out the remaining paint from the container.
2. Put proper thinner in the container and trigger the sprayer for approx. 2 seconds.
3. Pull the main plug out of the socket.
4. Disassemble the spray gun as shown in Illus. 8 (spare parts).
5. Thoroughly clean all soiled parts.
6. Reassemble the parts in reverse order.
7. Put a few drops of oil (e.g. sewing machine oil) in the intake and runback holes
(Illus. 6, arrow). Briefly switch on the spray gun.
Flexible Nozzle Extension (Illus. 7)
For spraying ceilings, resting objects or hard-to-reach areas e.g. radiators
Accessories W 140 P
(not included in scope of delivery)
Designation Order No.
Round spray nozzles for various spray materials:
Very thin spray materials/nozzle size: 0,5 0046 894
Paint container with cover 0413 909
Flexible nozzle extension with atomiser 0046 675
