GB
9
Spray gun W 140 P
Important Note Regarding Product Liability!
Using other accessories and spare parts can lead to partial or total loss of liability and
guarantee claims. With original WAGNER accessories and spare parts, you have the
guarantee that all safety regulations are fulfilled.
Malfunction Cause Correction
Spray gun buzzes and does Piston stuck Disassemble pump and
not work clean with thinner
Defective drive Send spray gun to customer
service center
Spray gun does not suck in No valve in the pump Insert valve
Spray gun sucks in but does Nozzle clogged Clean
not spray Ducts and holes in atomiser clogged Clean
Spray gun works but sprays Spray material in container running
unevenly out Refill
Spray gun held inclined leading to Use flexible nozzle
sucking in of air extension (see accessories)
Viscosity of spray material too high
(too thick) Dilute accordingly
Fine adjustment button not set Reset according to spray
correctly material
Nozzle worn out Replace
Valve worn out Replace
Wrong valve inserted Use correct valve
Spare Parts List W 140 P
Pos Name Order No.
1 Suction tube 0413 305
2 Paint container with cover 0413 909
3 Nozzle 0,8 mm 0046 903
4 Locking nut 0413 310
5 Valve 0209 042
6 Pump housing 0412 210
7 Piston spring 0033 028
8 Piston 0198 207
9 Nozzle spanner 0199 327
10 Viscosity measuring cup 0209 058
