WAGO 750-370 User Manual

86 • PROFINET IO 750-370
Process Image
WAGO-I/O-SYSTEM 750
PROFINET IO
No. I/O module Module PA I/O Controller *
Identifier Inputs Outputs
Digital output --- A 9.0
Digital output --- A 9.1
Digital output --- A 9.2
Digital output --- A 9.3
Digital output --- A 9.4
Digital output --- A 9.5
Digital output --- A 9.6
8
Digital output
75x-530* 8DA(-8 BIT A)
(-)
--- A 9.7
Digital output --- A 10.0
Digital output --- A 10.1
Digital output --- A 10.2
Digital output --- A 10.3
Digital output --- A 10.4
Digital output --- A 10.5
Digital output --- A 10.6
9
Digital output
75x-530* 8DA(-8 BIT A)
(-)
--- A 10.7
10 Power supply
750-610 P-Supply, DIA
(-)
--- ---
Analog output --- AW 256 11
Analog output
750-550 2AA, 0-10 V
(INT16[2] OUT)
--- AW 258
Analog input EW 260 --- 12
Analog input
750-452 2AE, 0-20 mA
(INT16[2] IN)
EW 262 ---
Analog output EB264, EW265 AB264, AW265 13
Analog output
750-550 2AA, 0-10 V, EM
({UINT8, INT16}[2] IN/OUT)
EB267, EW268 AB267, AW268
Analog input EB270, EW271 AB270, AW271 14
Analog input
750-452 2AE, 0-20 mA, EM
{UINT8, INT16}[2] IN/OUT
EB273, EW274 AB273, AW274
15 Power supply
750-610 P-Supply.
2DIA(+6 BIT E),
DIA in E-PA
(UINT8)
E 14.0
...
E 14.1
---
Digital output --- A 11.0
Digital output --- A 11.1
Digital output --- A 11.2
16
Digital output
75x-504 4DA(+4 BIT A)
(UINT8 OUT)
--- A 11.3
17 End module End module --- ---
* The addresses stated in the table correspond with the process data allocation given in the
hardware configuration.
