Additional Controls and Connectors of the XTk
The XTk features the same controls and connectors as the MicroWave XT. In addition it
offers a 4 octave keyboard, a pitchbend and a modulation wheel, as well as numeric keys
and a select button for easy program access. The items labeled on this page indicate special
features that are available on the XTk only.
Front Panel
Rear Panel
쐅 Pedal / CV In jacks for connecting foot controllers or analog voltages
헀 Keyboard Section
헁 Numeric keys for selecting programs
헂 Select key with Hold led
헃 Controller Section with pitchbend wheel, modulation wheel and Octave Up /
Octave Down buttons
