12
Use only genuine Walker
®
replacement parts.
PARTS LIST (A54)
Parts Lists and Diagrams
ITEM PART DESCRIPTION NO.
NO. NO. REQ’D
ITEM PART DESCRIPTION NO.
NO. NO. REQ’D
48” & 52” Deck Height Adjuster Kit
1 7211-1 Lift Rod Weldment / DHA 48” 1
2 7211-8 Pivot Saddle / DHA 2
3 7211-2 Lift Arm, RH / DHA 1
4 7211-3 Lift Arm, LH / DHA 1
5 7211-9 Lift Saddle / DHA 4
6 7211-4 Saddle Lift Arm / DHA 4
7 7211-6 Inner Pivot Plate, RH / DHA 1
(Includes Item # 41)
8 7211-10 Pivot Plate, RH / DHA 1
9 7211-42 Height Plate / DHA 1
10 7211-11 Inner Pivot Plate, LH / DHA 1
11 7211-7 Pivot Plate, LH / DHA 1
12 7210-5 Lockout Arm 1
13 7210-4 Height Adjustment Arm 1
(Includes Item # 15)
14 7210-13 Outside Guard / DHA 2
15 5850-3 Handle Grip, Foam (3-1/4) 1
16 7210-14 Inside Guard, RH / DHA 1
17 7210-6 Guard Mount Inside 3
18 5155-13 10 mm Ball Stud, 5/16-18 x 3/4 1
19 7210-9 Front Lift Link 4
20 7210-8 Rear Lift Link 4
21 7210-10 Lift Rod Bracket 2
22 5665 Compression Spring (1/2 x 1) 1
23 6325-9 Spacer Bushing (5/8 x 5/16 x .280) 1
24 6325-11 Spacer (.5 x .250 x .375) 4
25 7211-17 Lifting Cross Tube / DHA 1
26 2215-16 Gas Spring Assembly 1
27 5213-9 Control Rod (16-1/2”) 2
28 5280-5 Clevis Fork, Long (5/16) 4
29 7211-12 Gas Spring Cover 48, 52 / DHA 1
30 7211-13 Pivot Bushing (1/2 x 5/16 x 1.468) 1
31 2722-8 Foot Pedal / DS60/DS52 1
32 7211-15 Foot Pedal Link 48, 52 / DHA 1
33 7211-16 Foot Pedal Arm 1
34 5146-2 10mm Ball Stud, 5/16-18 x 1 1
35 7211-14 Inner Retainer 2
36 6325-14 Spacer (1.0 x 5/16 x 5/16) 2
37 8600-38 Decal, Deck Height Adj 1
38 7775-9 Wire Lock Pin (5/16 x 1-3/8) 1
39 7434-1 Washer 1-3/8 x 5/8-1/2 Thick 4
40 4452-6 Steering Pivot (1/4-20 x 1-5/8) 1
41 5830 Grease Fitting 1
42 5847 Plastic Tip 1
43 7211-18 RH Lift Saddle 1*
44 7211-19 LH Lift Saddle 1*
45 2720-3 Spacer (9/16 x 5/16 x .438) 1
Fasteners
F024 5/16-24 Jam Nut 4
F031 1/4-20 x 5/8 Hex Bolt 2
F034 5/16-18 x 3/4 Hex Bolt 7
F038 3/8-16 x 1 Hex Bolt 1
F049 5/16 SAE Washer 3
F050 1/4 SAE Washer 2
F093 5/16-18 x 1 Hex Bolt 2
F179 1/4-20 x 1 Hex Bolt 2
F208 5/16-18 x 2-1/4 Hex Bolt 1
F236 1/4-20 x 1-3/4 Hex Bolt 12
F271 1/4-20 x 2-1/4 Hex Bolt 2
F288 5/16-18 ESNA LP Nut 4
F350 1/4-20 LP Nylock 9
F398 1/4-20 x 2 Hex Bolt 2
F551 5/16-18 Flange Top Lock Nut 16
F552 Washer 1.250 x .314 x .125 2
F569 1/4-20 Flange Top Lock Nut 28**
F603 Washer .745 x .320 x .125 4
F645 5/16-18 x 1-1/8 Hex Bolt 3
F705 1/4-20 x 13/16 Hex Bolt 8
F706 5/16-18 x 1-1/16” Hex Bolt 4
F715 5/8 External Snap Ring 4
F716 5/16-18 x 4 Hex Bolt 1
F717 1/4-20 x 1/2 Button Head 8
* DM52 only
** Four (4) F569 are used on rear Lift Saddles of all decks except
DC48.
