COMPONENT IDENTIFICATION
NOTE: Operator Controls are identied in the
section Operating Controls on page 27.
Front View and Right Side View
Deck
Caster Wheels
Deck Lift Handle
(Cutting Height Adjustment)
Footrests
Deck Support
Pins and Height
Adjustment
Hitch Pins
Tilt-Up Latch
Deck Support
Arm
Counterweight Springs and
Protective Covers
Seat Panel
Latch
Forward Speed
Control (FSC)
Friction
Adjustment
Tilt-Up
Deck Handle
Deck
Support Arm
