B27i Operating Instructions
31
8600-5
PARKING BRAKE
THROTTLE
Reverse Drive
Wheel Motion
Position
Engaged
Position
Disengaged
Position
Forward Position
(No Control Change)
Full Forward
Ground Speed
Position
Neutral-Park
Position
BLADE CLUTCH (PTO)
Neutral-Park
Position
Intermediate
Ground Speed
Position
Fast
Throttle
Position
Idle
Position
Operating Controls (Top View from Drivers Point of View)
The Forward Speed Control also Establishes the Neutral-Park Position of the Steering Levers
RIGHT WHEEL
STEERING LEVER
LEFT WHEEL
STEERING LEVER
FORWARD SPEED
CONTROL LEVER (FSC)
