Specifications
5
MODEL MW
MOWER DECK
Width of Cut 36-, 42-, 48-, 52-, or 56-in.(91, 107, 122, 132, or 142 cm)
Cutting Height 1 to 4 in. (3 to 10 cm)
Height Adjustment 7 Positions - 1/2 in. (1 cm) Increment Hitch Pins Installed in
Multi-Position Deck Support
Blade Size
42 in. (107 cm) 22 in. (56 cm) 2 in. (5 cm) Center Overlap
(Two Blades, CW Rotation)
48 in. (122 cm) 48 in. (122 cm) 25 in. (64 cm) 2 in. (5 cm) Center Overlap
(Two Blades, CW Rotation)
Deck Suspension Torsion-Flex Frame with Caster Wheels and
Counterweight Springs
CURB WEIGHT (Approximate)
Tractor Only 370 lb (168 kg)
Tractor and Deck 520 lb (236 kg)
* Dimensions and weight shown are for 48 in. (122 cm) SD Deck (Typical)
DRIVE BELTS
Engine PTO Walker P/N 9230
Ground Drive Walker P/N 9248
FRAME/BODY CONSTRUCTION
Frame/Body 3/16 Plate Steel
Deck 11 Gauge Steel
NOTE: The manufacturer reserves the right to make changes in specifications shown herein at any time
without notice or obligation.
