Walker T23 - Component Identification; Front and Right Side Component Identification

Component Identication
7
Front View and Right Side View
NOTE: Control Identication
shown in Operating
Instructions section.
Deck
Caster Wheels
Anti-Scuff
Roller
Grass Handling System
10.0 Bushel Catcher
Footrests
Tilt-Up Hook
(Not Visible)
Tilt-Up
Deck Handle
Deck Lift Handle
(Cutting Height Adjustment)
Catcher Lift /
Dump Handle
Turbine
Precleaner
Deck Support Pins
and Height Adjustment
Hitch Pins
Counterweight Spring
and Protective Cover
Tilt-Up
Latch
Spring Clip
Transmission Control Rod
Adjustment Nuts
Deck Support
Arms
Fuel Tank
and Cap
