Specications
3
MODEL T30i
ENGINE
Manufacturer/Model Kohler Aegis
TM
LH775, 2 Cyl., Gasoline (Liquid-Cooled),
Electronic Fuel Injection (EFI)
Displacement cu. in. (cc) 45.6 (747)
Max. Power HP (kW) 30.0 (22.4) @ 3600 RPM
Governed RPM 3600
Max. Torque lb·ft (N·m)
47.7 (64.7)
Idle RPM 1200
Spark Plug Type
Champion
®
RC14YC
Spark Plug Gap in. (mm) .030 (0.76)
Crankcase Capacity qt (L) 1.7 (1.6)
Crankcase Lubricant API SJ or Higher Grade Oil Only with 10W-30 Viscosity Above 0° F
(-18° C), or 5W-20 or 5W-30 Viscosity Below 32° F (0° C)
Oil Filter Kohler P/N 12 050 01 S
Cooling System Liquid-Cooled
Cooling System Capacity gal (L)
(Approx.)
1.25 (4.73)
Coolant 50/50 Pre-Mix Antifreeze/Water
Cooling Fan
Electric Radiator Cooling Fan with Reversible Self-Cleaning Action
Fuel Tank Capacity gal (L) 4.7 (17.8)
Fuel Regular Grade Unleaded Gasoline
(87 Octane Minimum, 10% Ethanol Maximum)
Air Cleaner Remote Mounted Donaldson Radialseal
TM
(Walker P/N 5090-1 Primary/5090-3 Safety Filter)
ELECTRICAL SYSTEM
Battery
12 Volt, 41AH, 340 CCA (Interstate U1-SP40)
Charging System Flywheel Alternator
Charging Output
25 Amp DC (Regulated)
System Polarity Negative Ground
Ignition Electronic Capacitive Discharge
Starter 12 Volt Electric Ring-Gear Type, Solenoid Shift
Interlock Switches Ignition Lockout by Seat Switch,
Transmission Neutral and Blade Clutch
Circuit Breakers Auto Reset (40A) - Radiator Fan Circuit
Auto Reset (30A) - Electrical System
Manual Reset (10A) - Insturment Panel
Manual Reset (7A) - Instrument Panel
