Safety Instructions

SAFETY, CONTROL, AND INSTRUCTION DECALS

Safety, Control, and Instruction Decals are installed on the machine;

if any are missing, illegible, or damaged, a replacement should be ordered and installed before

putting the machine into operation. The Decal Part Number is listed below and in the Parts Manual.

Location: Right Side, Behind Operator Seat

Part Number: 8600-23

1. Warning – entanglement hazard.

● Remove ignition key before raising front

body.

2. Body Tilt Latch

● Raise lever to release.

● Lift at back of body to raise.

1. Caution - Pinch point.

● Keep all body parts clear when closing grass

catcher door.

Location: Catcher Door Hinge Bar,

LH and RH Sides

Part Number: 8600-10

Location: Hydrostat Oil Reservoir

Location: LH Gear Axle

Part Number: 5810-3

Location: Jackshaft Support Adjacent

to Dipstick

Part Number: 7827

Location: Front Body, RH Side Adjacent to

Operator Seat

Part Number: 8600-30

1. Parking Brake

● Move lever forward to engage Parking Brake;

back to disengage.

Location: Front Body, LH Side Adjacent to

Operator Seat

Part Number: 8600-31

1. Throttle

● Move lever forward to increase engine

speed; back to idle.

8600-23
