WAMGROUP TOREX VAR 100 User Manual

SPARE PARTS
ERSATZTEILE
PIECES DE RECHANGE
PEZZI DI RICAMBIO
3
03.11
-
-
-
-
VAR
TOR. 119.--.R.4L Rev. A1
MAIN SPARE PARTS LIST
ALLGEMEINE ERSATZTEILLISTE
LISTE PIECES DE RECHANGE GENERALE
LISTA RICAMBI GENERALE
02
Pos
Type VAR080 VAR100 VAR125 VAR150 VAR175 VAR200
Q.ty
Description Codes
1
Body (aluminium parts in contact) 20664101A 20664151A 20664201A 20664251A 20664301A 20664351A
1
Body (AISI 304 parts in contact) 20664102A 20664152A 20664202A 20664252A 20664302A 20664352A
2
Drum (aluminium parts in contact) 20664501A 20664551A 20664601A 20664651A 20664701A 20664751A
1
Drum (AISI 304 parts in contact) 20664502A 20664552A 20664602A 20664652A 20664702A 20664752A
3
Cover 20664901A 20664951A 20665001A 20665051A 20665101A 20665151A 1
4
Air connection 20939001A 3
5
Actuator fixing plate 20640001A 20640021A 1
6
Rear cover 20640011A 20640111A 1
7
Plexiglas disc 20639001A 1
8 Drive pin 20954001A 20954101A 1
9
Counter flange 20655001A 20655101A 20655201A 20655301A 20655401A 20655401A 3
10
Inlet gasket 20992201A 20992221A 20992241A 20992261A 20992281A 20992301A 3
11
Inflatable seal 2068350VA 2068360VA 2068370VA 2068380VA 2068390VA 2068400VA 3
12
Beari ng 3604ZK0090 (6908-2RS) 3604ZK2700 (6008-2RS) 3604ZK1605 (62210-2RS) 2
13
Sealing ring
2502FP2890 (DIN 3760-A ,
44/62/10)
2502FP4000 (DIN 3760-A ,
45/68/10)
2502FP3580 (DIN 3760-A ,
55/90/10)
2
14
Bearing locking snap ring Ø62 DIN 472 Ø68 DIN 472 Ø90 DIN 472 2
15 Drum locking ring nut GUK M40x1.5 Self-braking type Ring nut
M50x1.5
Self-braking type Ring nut
2
16
Actuator 6710VA0100 6710VA0150 6710VA0200 1
17
Micro switch Box 6710VA050 1
18
Actuator control solenoid valve unit 6720KP0000 1
19
Seals Control Solenoid valve Unit 6720010000 1
20 Seals air supply union 1/8" tube 6 mm Straight connector 1
21
Connector 90° 1/8" tube 6
3
22
3
23
Actuator air supply union 1/4" tube 10 mm Straight union 1
24
Actuator discharge regulator ¼" silenced discharge regulator 2
25
Seals discharge silencer 1/8" Silencer 1
26
1/8" F Cross connector 1
27
1/8"M-1/8"M taper nipple 1
28
Tube RILSAN d.6 -
29 Cover locking screw M8x20 ISO 4762 M8x25 ISO 4762 6
30
Cover screw washer Ø8 DIN 7980 6
31
Actuator - actuator plate connecting
screw
M8x16 ISO 4762 M10x16 ISO 4762 4
32
Actuator flat fixing screw
M8x20 ISO 4762
4
33 Idle side flat fixing screw 4
34
Counter flange flat fixing screw
M8x20 ISO
4762
M10x20 ISO
4762
M10x25 ISO 4762 18
35
Counter flange washer Ø8 DIN 7980 Ø10 DIN 7980 Washer Ø10 DIN 7980 18
36
Plexiglas cover fixing screw M4x10 ISO 4762 3
37
Drive pin fixing grub screw M5x5 ISO 4027 1
38
Seals solenoid valve fixing screws M4x30 ISO 4762 2
39
Actuator solenoid valve fixing screw M5x35 ISO 4762 2
Tab.1
Solenoid + connettori
6740010020 (Solenoid 24VAC + connettore)
6740010060 (Solenoid 110VAC + connettore)
6740010080 (Solenoid 230VAC + connettore)
6740010030 (Solenoid 24VDC + connettore)
