10.0 SPARE PARTS
VM
2
TOR.VM.--.M.A.0518.EN Issue: A
05.18
32
CONFIGURATION A
Item
Description Codes
Qty.
EQUIPMENT SIZE VM040 VM050 VM065 VM080 VM100
4
Aluminium threaded bushing 20973551A 20973651A 20973751A 20973851A 20973951A
2SS 304 threaded bushing 20973552A 20973652A 20973752A 20973852A 20973952A
Hardened threaded bushing 20973554A 20973654A 20973754A 20973854A 20973954A
5 Threaded bushing black seal 20680421A 20680411A 20680401A 2
6 Screw N.8 M6x20 ISO 4762 Cl.8.8
N.16
M6x25 ISO
4762 Cl.8.8
N.16 M6x25
ISO 4762
Cl.8.8
CONFIGURATION C
Item
Description Codes
Qty.
EQUIPMENT SIZE VM013 VM020 VM025 VM032
4 Polymer threaded bushing 20973401A 20973421A 20973441A 20973461A 2
6 Screw M4x20 ISO 4762 Cl.8.8 M4x25 ISO 4762 Cl.8.8 8
CONFIGURATION B
Item
Description Codes
Qty.
EQUIPMENT SIZE VM040 VM050 VM065 VM080 VM100 VM125 VM150 VM200
3
Standard aluminium
ange
20660021A 20660031A 20660041A 20660051B 20660061B 20660071A 20660081A 20660091A
2
Aluminium ange USA 20660031U 20660061U 20660071U 20660081U
4
Standard aluminium
bushing
20973501A 20973601A 20973701A Tab.D Tab.D 20974001A 20974101A 20974201A
2SS 304 standard
bushing
20973502A 20973602A 20973702A 20973802A 20973902A 20974002A 20974102A 20974202A
Hardened bushing 20973504A 20973604A 20973704A 20973804A 20973904A 20974004A 20974104A 20974204A
5
Standard black seal T-20680501A T-20680511A 20680521B 20680531B 20680541B 20680551B 20680561B 20680571B
2Standard white seal 20680502A 20680512A 20680522B 20680532B 20680542B 20680552B 20680562B 20680572B
Black seal USA 20680511U 20680541B 20680551B 20680561B
6 Screw N.8 M6x20 ISO 4762 Cl.8.8
N.16
M6x20 ISO
4762 Cl.8.8
N.16 M6x25
ISO 4762
Cl.8.8
N.16 M8x25 ISO 4762
Cl.8.8
N.16 M8x40
ISO 4762
Cl.8.8
CONFIGURATION D
Item
Description Codes
Qty.
EQUIPMENT SIZE VM013 VM020
3
Standard aluminium ange and bush-
ing
20660101A 20660151A
2
Aluminium ange and bushing USA 20660151U
5
Standard black seal 20680531B 20680541B
2Standard white seal 20680532B 20680542B
Black seal USA 20680541B
6 Screw M6x20 ISO 4762 Cl.8.8 M6x25 ISO 4762 Cl.8.8 16
