Wangen KL Series User Manual

Instruction Handbook KL
Chapter 7
BA KL V11 en 10/2014 page 7-4
7.7 Lubricant fill quantities
Table 1: Lubricant quantity for different sizes of joints
Line of products / series
Lubricant quantity (Litre)
KL 20S
0.02 per each side of the joint
KL 30S/T
0.07 per each side of the joint
KL 50S/T
0.25 per each side of the joint
KL 80S/T
0.90 per each side of the joint
Table 2: Lubricant quantity for drive unit seal (LWD)
Line of products / series
Lubricant quantity (Litre)
KL 20S/T/R
0.015
KL 30S/T/R
0.035
KL 50S/T/R/RQ
0.15
KL 65S/T/R/RQ
0.19
KL 80S/R/RQ
0.3
Table 3: Lubricant quantity for roller bearings
Line of products / series
Lubricant quantity (kg)
KL 80
approx. 3.50
KL 100
Approx. 10.00
Possible damage
 Do not mix synthetic lubricants either with each other or with mineral lubricants!
ATTENTION
