2. Installation guide
2.1. Wired connection to LAN
Power on the IP camera（please check carefully the voltage of power adaptor, don’t
insert incorrect power, otherwise it will be damaged）, connect IP camera to router by
network cable and connect computer to the same router, example of figure 1.
Figure 1
Insert attached CD to computer driver, double click “H&MSearch_en.exe” in the CD,
will pop up the interface as figure 2, please operate as the following steps:
Figure 2
1) Click “Search”（Please make sure your firewall will not block up the item to be
searched）
2) Choose a camera;
3) Change the ip address of the ip camera according to the information in the red
