WARN INDUSTRIES PAGE 3 80565A1
©2007 Warn Industries, Inc.
WARN® and the WARN logo are trademarks of Warn Industries Inc.
II. TOOLS REQUIRED
• 3/8" Ratchet and 3-1/2" extension
• Sockets: 10mm, 12mm, 13mm
• Wrenches: 13mm
• Flat Blade Screwdriver
I. PARTS LIST
Ref Description Qty
A1 Plow Mounting Plate 1
B1 Flange Hd M8-1.25 x 30mm 6
B2 Flat Washer 5/16” 4
B3 Lock Nut M8 4
B4 Spacer 5/16x3/8x3/4 Alum 2
C1 Tab Plow RH Jogged 1
C2 Tab Plow LH Jogged 1
C3 Pin, Plow Retaining 2
