Warn 92332 - TORQUE SPECIFICATIONS

To Next Page

To Previous Page

NOTICE

EQUIPMENT DAMAGE

• AlwaysrefertotheInstallationandSpecicationGuide,suppliedinthewinchkit,forallwiringschematicsandspecicdetailsonhowtowirethisWARNproducttoyourvehicle.

Read installation and operating instructions thoroughly.

CAUTION

MOVING PARTS ENTANGLEMENT HAZARD

Failure to observe these instructions could lead to minor or moderate injury

• AlwaystaketimetofullyreadandunderstandtheinstallationandOperationsGuideincludedwiththisproduct.

• Neveroperatethisproductifyouareunder16yearsofage.

• Neveroperatethisproductwhenundertheinuenceofdrugs,alcoholormedications.

Read installation and operating instructions thoroughly.

NOTES

TABLE OF CONTENTS

Parts List.........................................................................................................................................page 2

Torque Specications ................................................................................................................page 2

Tools Required ............................................................................................................................. page 3

Installation .................................................................................................................................. page 4-

Maintenance/Care ......................................................................................................................... page

• For 2500 - 3500 winches only

TORQUE SPECIFICATIONS

Please use the recommended torque specications when assembling this product unless otherwise specied in the instructions.

FASTENER SIZE FASTENER TORQUE

lb-ft (N.m)

1/4" 8 (11)

5/16" 17 (23)

3/8" 30 (40)

7/16” 48 (66)

1/2" 74 (100)

9/16” 106 (144)
