©2014 Warn Industries, Inc.WARN® and the WARN logo are trademarks of Warn Industries Inc. 5 93900A0
c. Use side cutters to pop out plastic snap rivit (one on
each side). Set aside to reuse later.
4. Figure 5 shows plastic skid plate removed.
Next you will need to cut the plastic guard in order for the
plow mount to t correctly. NOTE: Suggested tools to cut
skid plate: tin snips, hack saw or utility knife.
5. With plastic skid plate on a at and level surface, line the rear
of plow mount plate with the middle of the skid plate.
Figure 4
Figure 5
Figure 6
Front of Vehicle
To Next Page
