WARRIOR W0700R - Trunnion Part List

Trunnion Part List
ITEM
DESCRIPTION
Q'TY
ITEM
DESCRIPTION
Q'TY
ITEM
DESCRIPTION
Q'TY
1
Handwheel Handle M10*100
2
36
Lock Nut M8
2
71
F-Trunnion Hanging Plate
1
2
Handwheel Locking
2
37
Gasket Plate
1
72
Square Nut M16*2
1
3
Handwheel
2
38
E-Retaining Ring φ52
1
73
Saw Gland
1
4
Cap Screw M6*30
4
39
C-Plate Fixing Plate
1
74
Saw Shaft
1
5
Lock Washer 6
12
40
Cap Screw M6*8
2
75
Bearing 6203
2
6
Washer 6
10
41
Set Screw M6*6
4
76
L-Fixing Sleeve
1
7
Set Screw M6*12
6
42
Set Screw M4*10
3
77
Saw Shaft Sleeve
1
8
R-Trunnion Rotating Plate
1
43
C-Plate Locking Plate
1
78
Lock Washer 10
7
9
Flange
1
44
C-Plate Lock Nut
1
79
Key 6*30
2
10
Lock Washer 8
6
45
C-Plate Locking Handle
1
80
Fixed Shaft
1
11
Cap Screw M8*25
2
46
C-Plate L-Handle Sleeve
1
81
P-Wedge Belt PJ10Z260J
1
12
Spacer（φ35-φ20-3）
4
47
Fixed Baffle
1
82
Pulley
1
13
Flat Bond 5*25
2
48
Washer 4
4
83
Key 5*16
1
14
Angle Turbing Shaft
1
49
Lock Washer 4
5
84
S-Fixing Sleeve
1
15
Handwheel Locking Column
4
50
Button Head Screw M4*8
4
85
Set Screw M8*12
1
16
Fixing Sleeve
2
51
Round Nut M16*1.5
1
86
Motor Handing Board
1
17
Angle Screw Fixing Block
1
52
Fixing Plate
1
87
Flat Washer 10
2
18
Lifting Turbine
2
53
Falte Washer 5
3
88
Lock Nut M16*1.5
1
19
Lifting Turbine Shaft
1
54
Lock Washer 5
7
89
Bracket
1
20
Cap Screw M10*30
2
55
Button Head Screw M5*10
3
90
Fixed Shaft Of Motor
1
21
R-Tunnion Hanging Plate
1
56
Connecting Rod
1
91
Cotter Pin φ2.5*25
2
22
Tension Pin 4*28
2
57
Locking Ring
2
92
Hex Bolt M10*25
2
23
Long Copper Sleeve
1
58
Vacuum Tube（100mm）
1
93
Motor
1
24
Set Screw M8*8
4
59
Shield Integration
1
94
Key 6*25
1
25
Hex Nut M8
4
60
Flat Washer 6
2
95
Motor Pulley
1
26
Hex Bolt M8*20
2
61
Button Head Screw M6*16
2
96
Cap Screw M8*40
4
27
C-Board Integration
1
62
Connecting Rod Screw A
2
97
Flat Washer 8
8
28
Cap Screw M6*12
6
63
Skate
1
98
Nut M8
4
29
Hex Bolt M10-45(L)
1
64
Spacer Sleeve
2
99
Pointer Integration
1
30
Brake Pin Fixing Block
1
65
Connecting Plate
1
100
Washer 5
4
31
Compression Spring
1
66
S-Copper Sleeve
1
101
Cap Screw M5*16
4
32
Brake Pin
1
67
Washer（φ25*φ17*2）
1
102
Angle Pointer
1
33
Connecting Rod Screw
2
68
Lock Nut M16
1
103
Flat Washer 4
1
34
Wsher 10
2
69
F-Trunnion Plate
1
104
P-Head Screw M4*8
1
35
C-Plate Follower Plate
1
70
Hex Bolt M10*40
3
