Wasco LS 1003 E - Drain, Feet, and Electrical Connections

20/EN
Washing Machine / User’s Manual
points. If any leaks occur, turn off the tap and remove the
nut.Retightenthenutcarefullyaftercheckingtheseal.To
preventwaterleakagesanddamagescausedbythem,
keepthetapsclosedwhenthemachineisnotinuse.
2.5 Connecting to the drain
• Theendofthedrainhosemustbedirectlyconnectedto
thewastewaterdrainortothewashbasin.
A
warning: Yourhousewillbefloodedifthehosecomes
outofitshousingduringwaterdischarge.Moreover,there
isriskofscaldingduetohighwashingtemperatures!
Topreventsuchsituationsandtoensuresmoothwater
intakeanddischargeofthemachine,fixtheendofthe
discharge hose tightly so that it cannot come out.
• Thehoseshouldbeattachedtoaheightofatleast40
cm, and 100 cm at most.
• Incasethehoseiselevatedafterlayingitonthefloor
level or close to the ground (less than 40 cm above the
ground),waterdischargebecomesmoredifficultandthe
laundrymaycomeoutexcessivelywet.Therefore,follow
the heights described in the figure.
• Topreventflowingofdirtywaterbackintothemachine
andtoallowforeasydischarge,donotimmersethehose
endintothedirtywaterordonotdriveitinthedrainmore
than 15 cm. If it is too long, cut it short.
• Theendofthehoseshouldnotbebent,itshouldnotbe
steppedonandthehosemustnotbepinchedbetween
the drain and the machine.
• Ifthelengthofthehoseistooshort,useitbyadding
anoriginalextensionhose.Lengthofthehosemay
notbelongerthan3.2m.Toavoidwaterleakfailures,
theconnectionbetweentheextensionhoseandthe
drainhoseoftheproductmustbefittedwellwithan
appropriate clamp as not to come off and leak.
2.6 Adjusting the feet
A
warning: In order to ensure that the product operates
more silently and vibration-free, it must stand level and
balanced on its feet. Balance the machine by adjusting
thefeet.Otherwise,theproductmaymovefromitsplace
and cause crushing and vibration problems.
1. Loosen the lock nuts on the feet by hand.
2. Adjust the feet until the product stands level and
balanced.
3.Tightenalllocknutsagainbyhand.
A
warning: Do not use any tools to loosen the lock nuts.
Otherwise,theywillgetdamaged.
2.7 Electrical connection
Connect the product to a grounded outlet protected by a 16
Afuse.Ourcompanyshallnotbeliableforanydamages
thatwillarisewhentheproductisusedwithoutgroundingin
accordancewiththelocalregulations.
• Connectionmustcomplywithnationalregulations.
• Powercableplugmustbewithineasyreachafter
installation.
• Ifthecurrentvalueofthefuseorbreakerinthehouseis
less than 16 Amps, have a qualified electrician install a
16 Amp fuse.
• Thevoltagespecifiedinthe"Technicalspecifications"
section must be equal to your mains voltage.
• Donotmakeconnectionsviaextensioncablesormulti-
plugs.
B
warning: Damagedpowercablesmustbereplacedby
theAuthorizedServiceAgents.
Transportation of the product
1.Unplugtheproductbeforetransportingit.
2.Removewaterdrainandwatersupplyconnections.
3.Drainallwaterthathasremainedintheproduct.
4. Install transportation safety bolts in the reverse order of
removal procedure;
C
Nevermovetheproductwithoutthetransportationsafety
boltsproperlyfixedinplace!
A
warning: Packagingmaterialsaredangeroustochildren.
Keeppackagingmaterialsinasafeplaceawayfrom
reach of the children.
