Wasco LS 1003 E - Draining Water and Cleaning Pump Filter

30/EN
Washing Machine / User’s Manual
3. Some of our products have emergency draining hose and
somedoesnothave.Followthestepsbelowtodischarge
thewater.
Dischargingthewaterwhentheproducthasanemergency
draining hose:
a.Pulltheemergencydraininghoseoutfromitsseat
b.Placealargecontainerattheendofthehose.Drainthe
waterintothecontainerbypullingouttheplugattheend
of the hose. When the container is full, block the inlet
of the hose by replacing the plug. After the container is
emptied,repeattheaboveproceduretodrainthewaterin
the machine completely.
c. Whendrainingofwaterisfinished,closetheendbythe
plugagainandfixthehoseinitsplace.
d.Turnthepumpfiltertotakeitout.
Dischargingthewaterwhentheproductdoesnothavean
emergency draining hose:
a.Placealargecontainerinfrontofthefiltertocatchwater
from the filter.
b.Loosenpumpfilter(anticlockwise)untilwaterstartsto
flow.Filltheflowingwaterintothecontaineryouhave
placedinfrontofthefilter.Alwayskeepapieceofcloth
handytoabsorbanyspilledwater.
c. Whenthewaterinsidethemachineisfinished,takeout
the filter completely by turning it.
4.Cleananyresiduesinsidethefilteraswellasfibers,if
any, around the pump impeller region.
5. Install the filter.
6.Ifthefiltercapiscomposedoftwopieces,closethefilter
cap by pressing on the tab. If it is one piece, seat the tabs
inthelowerpartintotheirplacesfirst,andthenpressthe
upper part to close.
1. Close the taps.
2.Removethenutsofthewaterintakehosestoaccess
thefiltersonthewaterintakevalves.Cleanthemwithan
appropriate brush. If the filters are too dirty, take them out
by means of pliers and clean them.
3.Takeoutthefiltersontheflatendsofthewaterintake
hosestogetherwiththegasketsandcleanthoroughly
underrunningwater.
4. Replace the gaskets and filters carefully in their places
and tighten the hose nuts by hand.
5.5 Draining remaining water and
cleaning the pump filter
Thefiltersysteminyourmachinepreventssoliditems
such as buttons, coins and fabric fibers clogging the pump
impellerduringdischargeofwashingwater.Thus,thewater
willbedischargedwithoutanyproblemandtheservicelife
ofthepumpwillextend.
Ifthemachinefailstodrainwater,thepumpfilterisclogged.
Filtermustbecleanedwheneveritiscloggedorinevery3
months. Water must be drained off first to clean the pump
filter.
Inaddition,priortotransportingthemachine(e.g.,when
movingtoanotherhouse)andincaseoffreezingofthe
water,watermayhavetobedrainedcompletely.
A
warning: Foreignsubstancesleftinthepumpfiltermay
damage your machine or may cause noise problem.
Inordertocleanthedirtyfilteranddischargethewater:
1.Unplugthemachinetocutoffthesupplypower.
A
warning: Temperatureofthewaterinsidethemachine
mayriseupto90ºC.Toavoidburningrisk,filtermustbe
cleanedafterthewaterinthemachinecoolsdown.
2.Openthefiltercap.
 Ifthefiltercapiscomposedoftwopieces,pressthe
tabonthefiltercapdownwardsandpullthepieceout
towardsyourself.
If the filter cap is one piece, pull the cap from both sides at
the top to open.
C
You can remove the filter cover by slightly pushing
downwardswithathinplastictippedtool,throughthe
gap above the filter cover. Do not use metal tipped tools
to remove the cover.
