Wascomat SU630 - Page 67

67
I/O modules
14
6634, 6635
15
6236

























Outputs
• Externalpowersupply(e.g.24VDC)for
pumpsistobeconnectedto9and10.If
theinternalpowersupply(fromthewashing
machine)istobeused,itmaybetakenfrom
1(N)andconnectedto9andfrom2(L)and
connectedto10.Theoutputsmaybeloaded
withmax0.5A.
• Signalsforpumps1-5aretobeconnected
toconnections12-16where:
 12=Detergentsignal1
 13=Detergentsignal2
 14=Detergentsignal3
 15=Detergentsignal4
 16=Detergentsignal5
• Theprogramsheldonthemachinecanbe
foundonthemachine’sdataplate.
3M14* 3F01* 3R01* 3F02* Otherprograms
Signal1 – Prewash Prewash Prewash Prewash
Signal2 Mainwash Mainwash Mainwash Mainwash Mainwash
Signal3 Rinseagent Rinseagent Rinseagent Rinseagent Rinseagent
Signal4 Moplastrinse Disinfection Lastrinse Mainwash –
Signal5 Bleachingagent Bleachingagent Bleachingagent Bleachingagent Bleachingagent
*M=Mop,F=Farm,R=Restaurant
Inputs
• Thesignallevelmaybe5-24VDC/ACor100
-240VAC.At5-24V,thesignalreference
mustbeconnectedto3andat100-240Vto
4.
NOTE!
Do not mix potentials on the inputs.
NOTE!
Connecting excessive voltage (> 24V) to
connection 3 may damage the I/O module.
14
15
