WaterTech softmax - Plumbing Connection; Typical Plumbing Installation

Plumbing Connection
UDZ
ZDWHULQ
UDZZDWHUWR
RXWVLGHIDXFHWV
FRQGLWLRQHG
ZDWHULQ
KRW
FROG
KRWZDWHUKHDWHU
7ULWRQ%\SDVV9DOYH
Typical Plumbing Installation
STOP
Check local codes
for minimum run
between unit and
water heater
Important: Brass or plastic
yoke assembly (not shown) is
required to connect piping to the
bypass valve and is available in
either NPT or solvent.
3
