Drain Line Connection

MDFR

MDFR

Air Gap
Drain Line
Drain Elbow Nut
PolyTube Insert
Drain Elbow
Locking Clip
CAUTION: Never connect drain line directly into drain,
sewer line or trap. Always allow an air gap of at least
25mm (1 inch) or 2 pipe diameters between the drain line
and waste water to prevent the possibility of sewage
4
