watt box WB-300VB-IP-5 User Manual

pg.8
WATTBOX™ WB-300VB-IP-5 Owners Manual
Outlets
Type NEMA 5-15
Number of Outlets 5 (separately controlled)
AC Power
Line Voltage 120V, 60Hz
AC Input Connection IEC C-14
Circuit Breaker Rating 15A
UL Current Rating 12A
Voltage Protection Rating (UL 1449 3rd Edition) 500V
Joule Rating 2160 Joules
Surge Component Ceramic Encased MOV
Protection Modes L-N, L-G, N-G
Peak Impulse Current 48,000A
Disconnect Circuitry Yes
Thermal Fuse Yes
EMI / RFI Noise Filtration
All Outlets 53dB, 1kHz to 1MHz
Operating Temperature Range
14 to 104°F (-10 to +40°C)
UL Certications
UL 60950-1, UL 1449, UL 498
UL 497A/B, UL 1283
Dimensions 7.9"W x 2.7"H x 6.75"D (w/o brackets)
Connected Equipment Warranty $50,000
SPECIFICATIONS
