Watts AMES Maxim Series User Manual

6
Parts
1
3
9
8
7
2
5
4
6
1
6
7
2
9
10
4
3
5
8
For repair kits and parts, refer to the Backflow Prevention Products,
Repair Kits, and Parts PL-AMES price list at watts.com.
ITEM NO. DESCRIPTION
1 First Check Module
2 Second Check Module
3 O-Ring, Check Module
4 Elastomer Disc
5 Grooved Check Pin
6 Closure Sleeve Test Cock
7 Closure Sleeve
8 Closure Sleeve O-Ring
9 Relief Valve Assembly
ITEM NO. DESCRIPTION
1 Relief Valve Assembly
2 Diaphragm
3 Spring
4 Spider Bushing
5 Piston Assembly
6 Body
7 Hose & Cover Plate
8 Cover Screw
9 Inlet coupler, O-ring,
10 ‘E’ Clip
