Setup WAVECOM Decoder W74PC, W-PCI/e, W-CODE, W-CLOUD Manual V9.1.0
W74PC has four SMA signal inputs. The following table is the technical hardware specification.
Specification
Card type
Half-size PCIe x4 card
Inputs
AFIF#1 – AFIF#4
IF70#1 – IF70#4
Frequency range
50 Hz – 25 MHz
52.5 MHz – 87.5 MHz (SAW filter)
Signal level
2 mVrms – 0.5 Vrms
20 mVrms – 2.5 Vrms
Input impedance
> 1 kOhm
50 Ohm
Bandwidth
5 kHz – 500 kHz
Frequency raster DDC
< 1.0 Hz
Input max sampling rate
98.304 MHz
Sampling rate jitter
< 1 ps (RMS 12 kHz to 20 MHz)
Connector
SMA female
Number of concurrent, independent inputs
Four SMA connectors: AFIF/IF70#1 – AFIF/IF70#4, each switch-
able by a mini signal relay
Dimensions (LxWxH)
168x106x22 mm
Weight
150 g
Power requirement (typical values)
< 25W
Bus interface
PCIe x4 link, 2 Gbit/s
Operating temperature range
0 °C to 50 °C
Case temperature range
0 °C to 55 °C
Storage temperature range
0 °C to 70 °C
Relatively humidity (non-condensing)
10 to 90%
A/D converter
2 x AD9268 dual 16-bit ADC
Dynamic range
> 60 dB
Digital down converter (DDC)
FPGA Cyclone IV
Oscillator and clock
High stability temperatur compensated crystal oscillator. Low
phase noise clock distribution
Watchdog for on-board generated voltage
Yes
License key
In-card license, no external license key necessary
Conformity
