AlphaBot 2 User Manual
2
share awesome hardware
To the Reader
Selection Guide
Note: Accessories may be different in different product package. This manual describes all the
compatible accessories but perhaps the product you bought doesn’t contain some of them. The
figure below shows most the compatible accessories:
Package Contents
Products
Item
Description
AlphaBot2-
Ar Acc
Pack
AlphaBot2
-Ar
AlphaBot2-
Pi Acc Pack
AlphaBot2-
PiZero Acc
Pack
AlphaBot2-Base
Motor driver, integrates sensors for
obstacle avoiding, line tracking
AlphaBot2-Ar
Adapter board, for connecting
Arduino
AlphaBot2-Pi
Adapter board, for connecting RPi3 B
AlphaBot2-PiZero
Adapter board, for connecting RPi
Zero W
RPi3 B
Raspberry Pi 3 Model B
UNO PLUS
Enhanced Arduino compatible board
Dual-mode Bluetooth
Dual-mode Bluetooth module
Ultrasonic sensor
Ultrasonic obstacle avoiding, ranging
IR remote controller
remotely control the robot
RPi Camera (B)
Raspberry Pi camera, adjustable focus
SG90
Servo, working with the pan head,
controlling the rotation of the camera
Micro SD Card 16GB
16GB Miro SD Card, class 10
5V 2.5A Power
Adapter
RPi3 B requires 2.5A or above power
supply
Note:
AlphaBot2-Ar Acc Pack requires an Arduino compatible controller, if you don't have one in hand,
please consider the all-in-one kits: AlphaBot2-Ar.
AlphaBot2-Pi Acc Pack requires the controller Raspberry Pi, if you don't have one in hand, please
consider the all-in-one kit: AlphaBot2-Pi.
AlphaBot2-PiZero Acc Pack requires the controller Raspberry Pi Zero/Zero W, which should be
purchased separately.
Due to the structure design, ultrasonic sensor module can NOT be used with the AlphaBot2-Pi kit.
