12
35XP Electrical Specifications
(at 23°C ± 5°C, < 75% R.H.)
DC VOLTS
Ranges: 400 mV, 4 V, 40 V, 400 V, 1000 V
Accuracy: ± (0.5% rdg + 1 dgt)
AC VOLTS (45 Hz to 500 Hz)
Ranges:400 mV, 4 V, 40 V, 400 V, 750 V
Accuracy: ± (1.5% rdg + 5 dgts) 45 Hz to
100 Hz on 400 mV range ± (1.5% rdg
+ 5 dgts) on 4 V to 750 V ranges
DC CURRENT
Ranges: 400 µA, 4000 µA, 40 mA, 400 mA,
2 A
Accuracy: ± (1.0% rdg + 2 dgts) on 400 µA
to 400 mA ranges ± (2.0% rdg + 3 dgts) on
2 A range
AC CURRENT (45 Hz to 500 Hz)
Ranges: 400 µA, 4000 µA, 40 mA, 400 mA,
2 A
Accuracy: ± (1.5% rdg + 5 dgts) on 400 µA
to 400 mA ranges ± (2.5% rdg + 5dgts) on
2 A range
RESISTANCE
Ranges: 400 Ω, 4 kΩ, 40 kΩ, 400 kΩ,
4 MΩ, 40 MΩ
Accuracy: ± (1.0% rdg + 4 dgts) on 400 to
4 MΩ ranges ± (3.0% rdg + 5 dgts) on
40 MΩ range
CONTINUITY
Audible indication: Less than 25 Ω
DIODE TEST
Test current: 1.2 mA (approximate)
Accuracy: ±(1.5% rdg + 3 dgts)
Open circuit volts: 3.0 dc typical
CAPACITANCE
Ranges: 4 nF, 40 nF, 400 nF, 4 µF, 40 µF,
400 µF, 4 mF
Accuracy: ± (5.0% rdg + 30 dgts) on 4 nF
ranges ± (5.0% rdg + 5 dgts) on 40 nF and
400 µF ranges ± (5.0% rdg + 15 dgts) on
4 mF range
TEMPERATURE
Ranges: -20°C to 1000°C, -4°F to 1832°F
Accuracy: ± (2.0% rdg +4°C) -20°C to 10°C
± (1.0% rdg + 3°C)10°C to 200°C
± (3.0% rdg + 2°C) 200°C to 1000°C
± (2.0% rdg + 8°F) -4°F to 50°F
± (1.0% rdg + 6°F) 50°F to 400°F
± (3.0% rdg + 4°F) 400°F to1832°F
FREQUENCY
Ranges: 4 k, 40 k, 400 k, 4 M, 20 MHz
Accuracy: ± (0.1% rdg + 3 dgts)
Sensitivity:
10 Hz to 4 MHz: >1.5V rms; 4 MHz to
20 MHz: >2 V rms, <5 V rms
NON-CONTACT VOLTAGE INDICATOR
Sense voltage 70 V to 600 VAC (50 Hz to
60 Hz) beeper chirps and bright green LED
comes on, works when meter dial is on any
range.
OVERLOAD PROTECTION:
Voltage, Resistance, Diode, Continuity,
Frequency, Temperature: 1000 VDC or
750 VAC rms
Current, Capacitance: 2 A / 1000 V fast
blow ceramic fuse 6.3 × 32 mm
A JACK: Input warning detects wrong
switch/input jack configuration
AUXILIARY FEATURES
DATA HOLD: Freeze the latest reading on
the display.
RANGE: Execute manual range mode.
AUTO Power off: After auto power off,
press (RANGE) button to restart the meter,
and the last reading of measurement will be
returned to the display.
