88 CHAPTER 9  CLICK 110
Note
This parameter can also be changed using the front panel menu or Click Supervisor.
e switch patterns for the two parameters are identical, but bus 1 is congured using
switches 1–4 (S1:1–4) while bus 2 is congured using switches 5–8 (S1:5–8).
S1: Bus 1 Baud Rate
1 2 3 4 Value
O – – – Software mode
On O O O 9600 bps
On O O On 19200 bps
On O On O 38400 bps
On O On On 57600 bps
On On O O 9600 bps
On On Off On 9600 bps
On On On O 9600 bps
On On On On 9600 bps
S2: Bus 2 Baud Rate
5 6 7 8 Value
O – – – Software mode
On O O O 9600 bps
On O O On 19200 bps
On O On O 38400 bps
On O On On 57600 bps
On On O O 9600 bps
On On Off On 9600 bps
On On On O 9600 bps
On On On On 9600 bps
Table 9.2 – DIP Switch Baud Rate Settings for Bus 1 (left) and Bus 2 (right)
As these tables show, if the switches are in any conguration besides the ones laid out in the
rst few rows of these tables, that bus will default to 9600 bps.
If switch 1/5 is on (up), Hardware mode is selected, meaning the baud rate can be cong-
ured using the DIP switches (as shown in Table 9.2 above), and Click Supervisor and the
front panel menu will be able to display the current setting, but not change it. (Dashes in the
table above indicate that the other three switches don’t aect Soware mode selection.) If
switch 1/5 is o (down), Soware mode is selected and Click Supervisor and the front panel
menu will be able to both display and change the current setting.
Channel Enable
e next parameter that can be congured is which of the output channels are enabled.
Enabling output channels is located on the second DIP switch, labeled S2, and is controlled
with switches 4–8 (S2:4–8).
Note
This can also be changed using the front panel menu or Click Supervisor.
