Wavin AS+ Technical Manual
3.3. Sound-insulating performance
The excellent sound protection properties of Wavin AS+
are primarily attributed to its thick-walled design as well as
special molecular structure and the high density of ~1.9 g/
cm
3
of the material used to make the pipes and fittings. This
property enables Wavin AS+ to absorb airborne sound as well
as structureborne sound.
Studies conducted at the Fraunhofer Institut für Bauphysik
(Fraunhofer Institute for Building Physics), Stuttgart, on Wavin
AS+ attest to its excellent sound absorption properties.
Wavin low noise bracket Volumetric flow rate* Meets standard
2 l/s 4 l/s
DIN 4109 (public minimum legal requirement) specification 30dB(A) 14 dB(A) 19 dB(A) ✔
VDI 4100 sound insulation level II/III specification 27/24 dB(A) 11 dB(A) 16 dB(A) ✔
Installation noise level in rear basement (P-BA 63/2019)
Wavin no noise bracket Volumetric flow rate Meets standard
2 l/s 4 l/s
DIN 4109 (public minimum legal requirement) specification 30dB(A) <10 dB(A) 13 dB(A) ✔
VDI 4100 sound insulation level II/III specification 27/24 dB(A) <10 dB(A) 10 dB(A) ✔
Installation noise level in rear basement (P-BA 64/2019)
With no noise
<10 dB(A) according to 63/2019
With low noise
14 dB(A) according to 64/2019
* Installation noise levels based on installation with Wavin system brackets.
