wavin AS+ - Low Noise Bracketing - Single Bracket

54
Wavin AS+ Technical Manual
Phone. +31(0)38 42 94 951
Wavin offers two types of installation using the Wavin low
noise bracket. The single bracket installation offering sound
performance as low as 14dB(A), and the No-noise installation
offering sound performance lower than 10dB(A).
5.3.1. low noise bracketing – single bracket – 14 dB(A)
The low noise installation makes use of a single “Wavin low
noise bracket” that can be used as a sliding and a fixed brac-
ket. The pipe bracket can be changed from sliding to fixed,
by removing the distance washer. See 5.2.1. “changing from
sliding to fixed”
Fig. 41: Low noise bracketing – 14dB(A).
