Day Indicator - Displays the day of the week.1.
Mesh Symbol - Displayed when connected to the neoHub.2.
Floor Limit Symbol - Displayed when the floor probe has reached the 3.
temperature limit set on feature 07.
Frost Symbol - Displayed when frost protection mode is active.4.
Flame Symbol - Displayed when the thermostat is calling for heat, flashes 5.
when optimum start is active.
Heat/Cool - Indicates the current operation mode, only shown when 6.
neoChill is connected to the system.
Floor/Room Temp - Indicates the current sensor mode.7.
Set - Displayed when changes are being made to the program schedule 8.
or current set point.
Key Lock Indicator - Displayed when the KeyLock is Locked.9.
Program Indicator - Displayed during programming to show which 10.
period is being altered.
Main Menu - Displays which option is currently selected.11.
Temperature Format - Degrees Celsius or Fahrenheit.12.
Temperature - Displays the current sensor temperature.13.
Cool On - Displayed when cooling is active.14.
Clock - Time displayed in 24 hour format.15.
Holiday Left - Displayed when the thermostat is in holiday mode.16.
Hold Left - Displayed when a temperature hold is active, the remaining 17.
time will be shown.
LCD Display
Mode 1 - Thermostat
