WBOX Technologies 0E-55LED - Mounting and Connecting - Part 3; HDMI Input Connection; AV1 Input Connection; VGA Input Connection

5
Mounting and Connecting
W
R
Y
Audio cable
Video cable
AV1 input connection
Connect to the devices
with AV output interface
(e.g. DVD, VCR, game console)
HDMI signal cable HDMI signal cable
Connect to the AV device
with HDMI interface
HDMI input connection
Y Yellow (VIDEO signal cable)
W White(AUDIO-L signal cable)
R Red (AUDIO-R signal cable)
VGA cable
VGA input connection
HDMI signal cable
Connect to the audio devices
with coaxial interface
Coaxial-out connection
Coaxial cable
Connect to the devices with
AV input interface (e.g. Monitor)
Video-out connection
Video cable
Y
