W
R
Audio cable
Component input connection
Connect to the device with
output interfaceYPbPr/YCbCr
G
B R
Mobile phone or other
equipments with MHL function
MHL function connection
Antenna connection
When connecting outdoor antenna to signal port of the TV set, please
turn off the main power switch on the TV set first. Do not approach the
outdoor antenna to high voltage mains power line to avoid electric shock.
The wired network antenna connected to the TV set must be isolated
from the protective grounding, or can cause fire or other hazards.
the
Warning
R F
YPbPr/ cableYCbCr
MHL signal cable
USB interface
Earphone port
G Green (Y signal cable)
B Blue (Pb/Cb signal cable)
W White(AUDIO-L signal cable)
R Red (AUDIO-R and Pr/Cr signal cables)
6
Mounting and Connecting
To Next Page
