TROUBLESHOOTING
7
COPYRIGHT © 2020 ADI
PROBLEM
POSSIBLE CAUSE
SOLUTION
Full-time surge protection
outlets stop providing power to
equipment.
Circuit breaker has tripped due to an
overload.
Turn the UPS off and unplug at least one
piece of equipment. Wait 10 seconds,
reset the circuit breaker by depressing
the button, and then turn the UPS on.
The UPS does not provide
expected runtime.
Battery not fully charged.
Recharge the battery by leaving the UPS
plugged in.
Battery is slightly worn out.
Call W Box Tech Support for assistance
(US/Canada/PR) 1-833-574-9124
The UPS will not turn on.
The on/off switch is designed to prevent
damage by rapidly turning it off and on.
Turn the UPS off. Wait 10 seconds and
then turn the UPS on.
The battery is worn out.
Call W Box Tech Support for assistance
(US/Canada/PR) 1-833-574-9124.
Mechanical problem.
Call W Box Tech Support for assistance
(US/Canada/PR) 1-833-574-9124
Power Management Software is
inactive.
The USB cable is not connected.
Connect the USB cable to the UPS unit
and an open USB port on the back of the
computer.
The unit is not providing battery power.
Shutdown your computer and turn the
UPS off. Wait 10 seconds and turn the
UPS on. This should reset the unit.
MODEL
0E-RCKMT700
Capacity
700VA / 400W
Nominal Input Voltage
90Vac to 140Vac
Input Frequency
60 Hz +/- 3 Hz(Auto-sensing)
AVR Function
Yes
On-Battery Output Voltage
120Vac +/- 5%
On-Battery Output Wave Form
Simulated Sine Wave
Operating Temperature
+ 32°F to 104°F / 0°C to 40°C
Size (W x H x D)
433 x 235 x 44mm (1U Rack) 17.05” x 9.25” x 1.75”
Weight
17.3lbs / 7.83kg
Battery Type
RB0690X2
Typical Battery Recharge Time
8 hours from total discharge
Typical Battery Life
3 to 6 years, depending on number of discharge/recharge cycles
Recommended Battery
Sealed Maintenance Free Lead Acid Battery
Safety Approvals
UL1778 5th, cUL CSA C22.2 No.107.3-05, FCC/DoC Class B
TECHNICAL SPECIFICATIONS
