17
6.3.2.2
When the deformation of the outside of the wheel, adopt this method to positioning to grantee
the accurate positioning of the steel rim inner hole and main shaft. It is suitable to the steel rim,
especially the thick ALU
Main shaft lower spring suitable cone wheel bowl quick nut
6.3.2.3 FLANGE DISK POSITIONING（OPTIONAL）
Suitable to the big tire assemble
Main shaft flange disk（fixed on the main shaft） wheel cone quick nut
NOTE: The choice on the cone should be adapted to the rim center hole and pay attention
to its direction. Or it will cause the inaccurate measurement.
6.4 INPUT VALUE
6.4.1 Input DIS（Distance）
Pull the scale to the inner position to add the weight and press the key to
