8
DECAL LOCATION DIAGRAM
Nameplate
Note: The following information coming from the nameplate.
The nameplate is stuck in the center to the top on the rear of the machine. The meaning of
each part is in the following：
CB 9XX B
With hood
Model
Computerized dynamic wheel balancer
B. CE certificate
This mark indicates that this model of machine has got the CE certificate
C、Series No The first 3numbers is the abbreviate of the model. The middle 4 is the
manufacture date and the last 4 is company product series number.
D、What on the cross line is the name and address of the company and under the cross line
not includes the above explained but the rated electrical parameters, such as voltage、
frequency、power、phase number & full load current, and the weight and manufacture date of
the machine.
If the B has noted in the model of the machine, it means the machine with the protection cover.
It means without the equipment of the protection cover if without the note of B.
