40 Series
7
Description Webasto 40 Series
General
Part no. 3394952_
Operation Continuous electric
Operation voltage (DC) [V] 12
Power (at 20 A, 12 V) [W] 240
Control panel Rocker switch
Installation method Frame and rails screwed on deck / roof / surface
Average installation time [h] 4
Frame materials AlMg Si 0.5
Surface treatment Anodized
Glass panel Glass, tempered, grey, 8 mm
Allowable weight Not designed as walking surface
Max. load 70 kg, including weight glass panel
assembly
(in accordance with ISO 12216)
Allowable temperature [°C] -10 to +75
Possibility to use as escape hatch No
Cut out dimensions
L1 Total length [mm] 915 +4 / -0
L2 Length straight part [mm] 890
W1 Width [mm] 1,320 +4 / -0
R1 Corner radius, front/rear [mm] 80 ± 2
R2 Cross curvature [mm] 7,620
R3 Front radius [mm] 2,032
Longitudinal curvature [mm] Uncurved
Dimensions marine roof
L3 Overall length [mm] 1,675 (1,875 in combination with fixed panel)
L4 Length glass panel [mm] 1,040
L5 Rail length [mm] 710 (910 in combination with fixed panel)
W2 Width [mm] 1,378
H Height [mm] 49
R4 Corner radius glass panel, rear [mm] 25
R5 Corner radius glass panel, front [mm] 100
R6 Front radius glass panel [mm] 2,055
R7 Cross curvature [mm] 7,669
Longitudinal curvature [mm] Uncurved
Glass panel displacement
“tilt” (Z-direction) [mm] 22
“slide” (X-direction) [mm] approx. 550
Weight
[kg] approx. 40 - 50
Optics
Colour glass panel Grey tinted
Interior Blank anodized
Glass panel fixation Bolted on mechanism
