Webasto FCF Series User Manual

** Slow Delay
Unit Dimensions & Technical Specifications
BTU Capacity 5000 9000 12000 16000 24000
Capacity in kW 1.5 2.6 3.5 4.6 7.5
Voltage (V) 115 230 230 115 230 230 115 230 230 115 230 230 115 Soft 230 230
Frequency (Hz) 60 50 60 60 50 60 60 50 60 60 50 60 60 50 60
Running Current (A) 5.8 3.8 2.5 8.3 4.9 4.6 11 4.6 5.6 12.4 6.2 8.4 20.4 8.6 12.5
Starting surge (A) 23.5 15.5 13.5 36.5 16.5 18 45 29 25 54.5 25.5 26.5 39 41 46
Starting Time (ms) 150 160 200 125 115 165 150 125 340 140 190 320 250 350
Refrigerant R410A R410A R410A R410A R410A
Net Weight (kg) 24 27 33 34 60
Shipping weight (kg) 28 32 38 39.5 68
Blower Output (m
3
/h) 300 450 550 750 1100
Dia. Cupro (mm) 16 16 16 16 16
H (mm) 295 310 330 330 382
H1 (mm) 260 260 290 290 326
H2 (mm) 54 54 54 54 56
P (mm) 285 380 380 450 595
D (mm) 100 100 125 125 127
L (mm) 408 408 438 454 529
L1 (mm) 280 280 280 295 382
L2 (mm) 380 395 410 440 519
**Suggest Breaker (A) 15 10 10 15 10 10 20 15 15 **25 20 20
30 25 25
Internal Fuse 3.15 AL 250V 3.15 AL 250V 3.15 AL 250V 3.15 AL 250V
3.15 AL 250V
Minimum Flow Rate
6l / min.
360l / hr.
1.584gal / min.
11l / min.
660l / hr.
2.904gal / min.
15l / min.
900l / hr.
3.960gal / min.
19l / min.
1140l / hr.
5.016gal / min.
28l / min.
1680l / hr.
7.392gal / min.
Recommended Flow Rate
10l / min.
600l / hr.
2.640gal / min.
15l / min.
900l / hr.
3.960gal / min.
20l / min.
1,200l / hr.
5.280gal / min.
25l / min.
1,500l / hr.
6.600gal / min.
32l / min.
1920l / hr.
8.448gal / min.
Recommended Pump
Iwaki WB 350
Pan World 30PX
Iwaki WB 500
Pan World 50PX
Iwaki WB 1000
Pan World 100PX
Iwaki WB 1000
Pan World 100PX
Iwaki WB 2000
Pan World 250 PS

Webasto FCF Series Specifications

General

Brand	Webasto
Model	FCF Series
Category	Air Conditioner
Language	English
