Webasto Mazda 6 - Underride Protection and Exhaust End Section

Mazda 6
1313440A_EN
20
1 Underride protection
2 Wheel well trim
3 Strut
4 Original vehicle bolt
Mounting
underride
protection
1
Exhaust end section
2 Hose clamp
Installing
exhaust
end
section
42 mm dia. hole at Position 3 in wheel well
trim
2. Align exhaust end section 3 flush on
red (rt) rubber isolator
1.
Mounting
rubber
isolator
42
1
4
2
3
43
1 2
2
44
1
3
