SUBARU Legacy / Outback
1302628C_EN
2
Table of Contents
Validity
Vehicle and engine types, equipment variants and national specifications not listed in these installation
instructions have not been tested. However, installation according to these installation instructions may
be possible.
The installation location of a digital timer and summer/winter switch should be confirmed with the end
customer before installation.
Manufacturer Model Type EG-BE No./ABE
SUBARU Legacy / Outback BL / BP e1 * 2001/116 * 0228 * ...
SUBARU Legacy / Outback BL / BPS e1 * 2001/116 * 0256 * ...
Engine type Engine model Output in kW Displacement in cm³
EJ20 Gasoline 101 1994
EJ20 Gasoline 110 1994
EJ20 Gasoline 121 1994
EJ25 Gasoline 121 2457
EJ25 Gasoline 127 2457
EZ30 Gasoline 180 3000
Validity 2
Heater Unit/Installation Kit 3
Foreword 3
General Instructions 3
Special Tools 3
Explanatory Notes on Document 4
Preliminary Work 5
Heater unit installation location 5
Electrical Connections 6
Fan connection Version A 7
Fan connection Version B 9
Remote option (Telestart) 11
Preparing heater unit 12
Preparing installation location 13
Exhaust system with manual transmission 16
Exhaust system with automatic transmission 17
Installing heater unit 18
Combustion air 19
Coolant connection 20
Fuel Connection 23
Final Work 27
Operating Instructions for End Customer 28
