16
These commodities, technology or software were exported from the United States in accordance
with the Export Administration Regulations. Diversion contrary to US law is prohibited.
INSTALLING THE CABLE HANGER
CABLE HANGER MOUNTING INSTRUCTION
1. Choose a location to install the cable hanger.
• The hanger should be located in practical proximity to both the utility
service and the location of your vehicle’s charge receptacle. Preferably
mounted to a wall stud. Drywall and masonry wall installations require the
use of appropriate inserts.
2. Measure up approximately 36” from the floor and mark the location.
3. Drill out the preferred mounting holes through the back of the cable hanger
using a
7
/
32
-inch drill bit.
4. Using a Phillips screwdriver, tighten the screws for the cable hanger.
