Webb WEH12R - Assembly

Webb Lawnmowers
Instruction Manual

COMPONENTS









ASSEMBLY
Itisrecommendedthatyouweargardeningglovesareworn,whenunpacking,adjusting,assembling
andmaintainingthelawnmower.

Removethemachineandcontentsfromthecarton.Besurethecartonisemptybeforediscarding.

Ifyourequireanyassistancewithregardstothecontentsofthelawnmowercontactus:
Tel:01793333212-Mon–Fri8.30am–5.30pm(excl.BankHolidays)
Email:customerservice@webblawnmowers.co.uk

STEP1–FITTINGTHEHANDLE
CAUTION
Thisoperationhastobedoneclosetothecuttingcylinderblade.Westronglyrecommendtheuse
ofthickgardeningglovesonbothhandsandthelawnmowerbodyissecuredtostopthecutting
cylinderbladefromrotating.

1. Aligntheholesonbothoftheupperhandleswiththoseonthemiddlehandles.
2. Securebothhandlestogetherusingwingnuts&boltsprovided.
3. Repeattheprocesswiththelowerhandle.
4. Locatethefixingpeg,positionedwithinthemainbodyrecessonthelawnmowerandslidethe
appropriatelowerhandleoverthepeg.
5. Nowattachtheupper&middlehandleassemblyfromfigure1tothelowerhandle.
6. Followstep4&5fortheoppositesidelowerhandle.


     









