PARTS DIAGRAM - WELT26 Machine
PARTS LIST - WELT26 Machine
Item No Part No. Description Qty
Item No Part No. Description Qty
1 WE02050080021 Driveshaft 1
29 WE70030070164 Trigger Housing - Right 1
2 WE02050080008 Support Shaft 1
30 WE02080020053 Handle Cover 1
3 WE02010010118 Shaft 1
31 WE70030180090 Sleeve 1
4 WE02020160039 Connector 1
32 WE03010010022 Screw M5x20 2
5 WE03090010076 Bearing 608-2RS/P5 2
33 WE02050050078 Stop Switch 1
6 WE02040030002 Bush 1
34 WE70030070047 Wire 1
7 WE03020020053 ScrewM5x12 1
35 WE02020110039 Spring 1
8 WE03020030005 Screw M5x20 1
36 WE02020110041 Spring 1
9 WE70070100002 Joint 1
37 WE70030070172 Safety Lever 1
10 WE02020100025 Holder 1
38 WE02020110040 Spring 1
11 WE03010020021 Screw M6x60 1
39 WE70030070074 Throttle Lever 1
12 WE02020160212 Bracket 1
40 WE02050040045 Throttle Cable 1
13 WE03010110098 Screw M5x10 1
41 WE03010010046 Screw M5x30 1
14 WE03040010012 Washer 6 1
42 WE70030070216 Trigger Housing - Left 1
15 WE03030070005 Nut M6 1
43 WE61350020002 Tube 1
16 WE70030030086 Guard 1
44 WE70080060047 Clutch Case Assembly 1
17 WE02020070028 Knife 1
45 WE02020050036 Clutch 1
18 WE03020020027 Screw M5x16 2
46 WE03120020004 Stop Ring 35 1
19 WE70030160006 Washer 1
47 WE03090010070 Bearing 6202-2RS/P5 1
20 WE61270090005 Handle Assembly 1
48 WE03120010005 Stop Ring 15 1
21 WE70030160032 Handle Clamp 1
49 WE70070060032 Clutch Case 1
22 WE03010010048 Screw M5x35 4
50 WE02080020104 Rubber Cover 1
23 WE70030160079 Handle 1
51 WE03010010056 Screw M5x14 1
24 WE70030180120 Bush 1
52 WE03010010058 Screw M5x25 2
25 WE61270040018 Throttle Trigger Assembly 1
53 WE70070080038 Upper Plate 1
26 WE03010010029 Screw M5x14 1
54 WE70070080039 Lower Plate 1
27 WE02020160213 Clamp 1
55 WE03010010060 Screw M6x20 4
28 WE03030080002 Nut M5 3
56 WE61270070023 Safety Cover 1
57 WE02050220016 Nylon Cutter Head 1
