Webb WER16HP - Lower Handlebar Assembly; Attaching Cables and Starter Cord

Remove and ensure you have all the parts
required for assembly (see page 2 for reference)
Parts required:
4 x Bolts
1. LOWER HANDLE BAR ASSEMBLY
3. ATTACHING THE SAFETY (OPC) CABLE
1.
2. Upper Handle Bar Assembly
Spring cord Guide and bolt.
3a
3b
3. Aaching the Transmission Cable
and bolt.
3a.
Pull the brake lever out of the right
side hole, tilt forward and lower towards
the mower.
3b.
Insert the end of the cable into the
hole in the lever and replace the lever
back into hole of the handle.
INSTRUCTION MANUAL
6. LOCATE THE STARTER CORD
6
The starter cord spring maybe located differently depending on the model
1. Lower Handle Bar Assembly
attach lower handle bar bolts.
take the weight of the handle
