Webb WER18HW - BASIC MAINTENANCE; Cutting System; Spark Plug

PARTS DIAGRAM - REAR AXLE ASSEMBLY
Item No Part Number Description Qty
1 WE113-54 Rear Axle with Height Adjustment Handle 1
2 WE115-9 Gearbox Assembly 1
3 WE114-7 Bush 2
4 WE114-8 Bearing 6001RS 2
5 WE115-10 Gasket 13x39.3x1 2
6 WE115-11 Inner Wheel Cover 2
7 WE114-11 Spring Washer 12 6
8 WE114-12 Ratchet Washer 4
9 WE114-9 Self-Propelled Spring 1
10 WE114-14 Drive Cog L 1
11 WE114-15 Drive Cog R 1
12 WE114-16 Drive Pin 6
13 WE115-12 Rear Wheel 10" 2
14 WE113-51 Wheel Bearing 4
15 WE113-52 Lock Nut M8 2
16 WE115-13 Rear Wheel Trim 2
17 WE114-17 Drive V Belt 1
