Webb WER18SPES - Deck Assembly

DECK ASSEMBLY
Part
No
Handy Part
Number
Handy Product Description
Qty
Part
No
Handy Part
Number
Handy Product Description
Qty
1
WE115-1
Deck
1
14
WE113-37
Hex Self-Tapping Screw M6x10/8.8
6
2
WE113-25
"O" Ring 11.2x2.65
1
15
WE113-38
Height Adjustment Spring
1
3
WE113-26
Hose Connector Inlet
1
16
WE113-39
Height Adjustment Rod
1
4
WE113-27
Hose Connector Nut M12x1.25
1
17
WE113-40
R Pin 1.5x25
2
5
WE113-28
Cable Stopper
1
18
WE113-41
Bolt M6x12
2
6
WE113-29
Left Handle Bracket
1
19
WE113-42
Lock Nut M6/8.8
2
7
WE113-30
Right Handle Bracket
1
20
WE113-47
Mulch Plug
1
8
WE113-31
Hex Bolt M8x14
4
21
WE118-7
B&S 775E Engine
1
9
WE113-32
Lock Nut M8
6
22
WE115-4
Side Discharge Bracket
1
10
WE115-2
Height Adjustment Board
1
23
WE115-5
Side Discharge Cover
1
11
WE113-34
Square Neck Bolt M8x15/8.8
2
24
WE115-6
Side Discharge Chute
1
12
WE113-35
Rear Drive Right Bracket
1
25
WE115-7
Side Discharge Shaft
1
13
WE113-36
Rear Drive Left Bracket
1
26
WE115-8
Side Discharge Spring
1
