1.2 Machine Description
The CF 2 soil compactors are machines of the walk-behind type used for compaction in road and trench
construction.
Propulsion
The CF-2 is driven by a Robin gasoline engine (1/9) or a Honda gasoline engine.
Important!
Please refer to paragraph 1.3 (Specifications) for performance details of the engine and the whole
machine.
Function
The engine (1/9) drives the vibrator via a V-belt. The vibrator is screwed down to the base plate
(1/6) and sets it vibrating. The vibrating base plate performs the vibration work and travelling motion.
Accessories
A damper plate (2.4.3) and a water sprinkler system (1/1 and 1/8) are available as optional extras. An
undercarriage (1/4) can be fitted to the machine to facilitate transport work.
Operation
The compactor is started with a reversible starter (2.5).
The machine is steered by means of the handle (1/3). The engine speed is controlled directly at the engine
(2.5).
